Mini NRF24L01 Wireless Module

Product Information:

NRF24L01 is a single-chip transceiver chip operating in the 2.4-2.5GHz world wide ISM frequency band. The wireless transceiver includes: frequency generator enhanced SchockBurstTM mode controller power amplifier crystal amplifier modulator demodulator output power channel selection and protocol settings can be set through the SPI interface for low current consumption, When working in transmission mode with a transmission power of 6dBm, the current consumption is 9.0mA. The acceptance mode is 12.3mA, and the current consumption mode is lower in power off mode and standby mode.

Support six channel data reception:

1. Low working voltage: 1.9-3.6V Low voltage operation

2. High speed rate: 2Mbps, which greatly reduces collision phenomena in wireless transmission due to the short air transmission time (software sets an air transmission rate of 1Mbps or 2Mbps)

3. Multi frequency point: 125 frequency points, meeting the needs of multi point communication and frequency hopping communication

4. Ultra small size: built-in 2.4GHz antenna, compact size, 15x29mm (including antenna)

5. Low power consumption: When working in response mode communication, fast air transmission and startup time greatly reduce current consumption.

6. Low application cost: NRF24L01 integrates all high-speed signal processing components related to the RF protocol, such as automatic retransmission of lost data packets and automatic generation of response signals. The SPI interface of NRF24L01 can be connected using the hardware SPI port of the microcontroller or simulated using the microcontroller I/O port. The internal FIFO can interface with various high and low speed microprocessors, making it easy to use low-cost microcontrollers.
