1/2/4/8-way 5V/12V/24V Relay Module Optocoupler Isolation High And Low Level Trigger Microcontroller Red BoardItem NO.: MK00867
-
Customized Requirements
- Quantity
-
-
- Product Name: 1/2/4/8-way 5V/12V/24V Relay Module Optocoupler Isolation High And Low Level Trigger Microcontroller Red Board
- Item NO.: MK00867
- Weight: 0.1 kg = 0.2205 lb = 3.5274 oz
- Category: Electronic Modules > Switch/Relay Module
- Tag: 5V , 12V , 24V , Relay Module , 1-way , 4-way , 8-way , 2-way , Optocoupler Isolation
- Creation Time: 2024-03-27
1/2/4/8-way 5V12V24V Relay Module
Module Size:
1 way: 50 * 25 * 18.5mm
2-way: 50 * 41 * 17.5MM
4-way: 75 * 51 * 16.5MM
8-way: 142 * 52 * 18MM
Module Interface:
1. DC+: Connected to the positive pole of the power supply (voltage according to relay requirements)
2. DC -: Connected to the negative pole of the power supply
3. IN: The relay can be controlled to engage at high or low levels
Relay Output Terminal:
1. NO: Normally open interface of the relay, suspended before the relay is pulled in, and short circuited to COM after pulling in
2. COM: Relay Common Interface
3. NC: Normally closed interface of the relay, short circuited to COM before relay engagement, suspended after engagement
High And Low Level Trigger Selection Terminal:
1. When the jumper is shorted to LOW, it is triggered at a low level;
2. When the jumper is short circuited to high, it is triggered at a high level.
