JDY-40 2.4G Wireless Serial Port Transparent Transmission Transmission Integrated Long-Distance Communication Module

JDY-40 2.4G Wireless Serial Port Transparent Transmission Transmission Integrated Long-Distance Communication ModuleItem NO.: JDY-40

US$ 3.25
Quantity
1Pcs
10Pcs
100Pcs
1000Pcs
5000Pcs
Customized Requirements
Quantity
Adding to cart succeed
JDY-40 2.4G Wireless Serial Port Transparent Transmission Transmission Integrated Long-Distance Communication Module
color:red,size:xxl
Subtotal: US$ 0
View My Cart

Copy and share this link on social network or send it to your friends

Copy
  • JDY-40 2.4G Wireless Serial Port Transparent



    Product Description:



    JDY-40 is developed using 2.4G technology, with a viewing distance of 120 meters and a serial communication interface. It is simple and fast to use, and you only need to understand the serial port knowledge to apply JDY-40 products!



    Technical Parameters:



    ● Model JDY-40

    ● Operating frequency band 2.4G

    ● Maximum transmission power of 12db

    ● Operating temperature -40 ℃ -80 ℃

    ● Receiving sensitivity -97db

    ● Transmission distance of 120 meters

    ● Operating voltage 2.2V-3.6V

    ● TX current 40mA

    ● RX current 24mA

    ● Sleep current 5uA

    ● Communication interface standard TTL serial port



    Application Scenario:



    1: 2.4G panel switch

    2: 2.4G remote control

    3: 2.4G transparent transmission

    4: Phone one-to-many control

    5: IO switch quantity control

    6: 2.4G toys

    7: Smart Home Control Application
