X9C103S/X9C503S Module 10K/50K Adjustable 100th Order Digital Potentiometer Circuit Board Module

X9C103S/X9C503S Module 10K/50K Adjustable 100th Order Digital Potentiometer Circuit Board ModuleItem NO.: X9C103S

US$ 4.61
Model
Quantity
1Pcs
10Pcs
100Pcs
1000Pcs
5000Pcs
Customized Requirements
Quantity
Adding to cart succeed
X9C103S/X9C503S Module 10K/50K Adjustable 100th Order Digital Potentiometer Circuit Board Module
color:red,size:xxl
Subtotal: US$ 0
View My Cart

Copy and share this link on social network or send it to your friends

Copy
  • X9C103S/X9C503S Module



    Instructions for use:



    1) Wide voltage (3V-5V) power supply. The chip is X9C103S/X9C503S; PCB board size: 2.7 * 1.3CM

    2) 10K/50K full range potentiometer.

    3) The middle tap of the potentiometer slides between 0-10k (X9C103S)/0-50K (X9C503S) for a total of 100 stages (typical impedance of the sliding end of the potentiometer is 40 ohms)

    4) The VL and VH ports of the digital potentiometer correspond to the low and high ends of the sliding resistor, respectively, allowing for an input voltage range of -5V to+5V.

    5) The digital potentiometer module comes with a testing program, which is written in C language and divided into modules. The code includes: main function, display sub function, button sub function, and header files of each module. The source code can be opened using KEIL4 for testing and learning.
