Customized Requirements
- Quantity
-
-
- Product Name: 18650 Charger 4.2V Lithium Battery Charger TEC4056 TP4056 Charger Module
- Item NO.: 186504.2V
- Weight: 0.1 kg = 0.2205 lb = 3.5274 oz
- Category: Electronic Modules > Power Module
- Tag: TP4056 , 18650 Charger , 4.2V Lithium Battery Charger , TEC4056 , Charger Module
- Creation Time: 2024-04-08
18650 Charger 4.2V Lithium Battery Charger
Product Description:
Design Scheme for 0.3A, 0.5A, 0.8A Three Stage Current Charging IC
No need for 220V connection, safe and reliable. The phone charger can provide power to it, and the charging connection adopts Android phone cable MICRO_ USB interface for easy use.
IC design scheme, high charging current accuracy, fully charged with 4.2V protection, and voltage accuracy of 1%.
Charging status LED indicator: red light for charging, green light for full charge.
Suitable for 18650 batteries without protective plates
The 0.3A, 0.5A, and 0.8A three level current can be set through external resistors. The two 0.3A, 0.5A position resistors are both current setting resistors, and the factory current setting is 0.8A. The buyer can change the current by removing the resistors, such as removing the 0.3A resistor and retaining the 0.5A resistor, which is the charging current of 0.5A.
This charger is sold without a charging cable.
Size: 95.9mm * 21.5mm * 23.2mm
