40W50WX2 Stereo Bluetooth Digital Amplifier Board 12V/24V 2.0 Dual Channel Knob Volume Adjustment Switch XY-AP50LItem NO.: XY-AP50L
-
Customized Requirements
- Quantity
-
-
- Product Name: 40W50WX2 Stereo Bluetooth Digital Amplifier Board 12V/24V 2.0 Dual Channel Knob Volume Adjustment Switch XY-AP50L
- Item NO.: XY-AP50L
- Weight: 0.1 kg = 0.2205 lb = 3.5274 oz
- Category: Electronic Modules > Audio Amplifier
- Tag: 2.0 Dual Channel , Stereo , Bluetooth Digital Amplifier Board , 40W50WX2 , Knob Volume Adjustment Switch , XY-AP50L
- Creation Time: 2024-05-03
XY-AP50L Bluetooth Digital Amplifier Board
Product parameters:
Product Name: Mini 50W+50W Stereo Bluetooth Digital Amplifier
Product model: XY-AP50L
Power supply voltage: DC: 5-24V (the higher the voltage, the greater the output power)
Bluetooth version: 5.0
Transmission distance: 15 meters (unobstructed)
Number of channels: left and right dual channels (stereo)
Adapted speaker: 30W~200W 4 Ω 8 Ω 16 Ω
Protection mechanism: power reverse protection, short circuit protection, self recovery overheating protection
Attention: The output power of the power supply should be greater than the output power of the amplifier, otherwise it will affect the sound quality
12V → 8 Ω/15W+15W, 4 Ω/20W+20W
15V → 8 Ω/18W+18W, 4 Ω/greater than 30W+30W
19V → 8 Ω/32W+32W, 4 Ω/greater than 45W+45W
24V → 8 Ω/40W+40W, 4 Ω/greater than 50W+50W
