High Power 100W Mono Digital Amplifier Board TDA7294 High Fidelity Audio Amplifier Board Module TDA7293

High Power 100W Mono Digital Amplifier Board TDA7294 High Fidelity Audio Amplifier Board Module TDA7293Item NO.: XH-M170

US$ 8.87
Model
TDA7293
TDA7294
Quantity
1Pcs
10Pcs
100Pcs
1000Pcs
5000Pcs
Customized Requirements
Quantity
Adding to cart succeed
High Power 100W Mono Digital Amplifier Board TDA7294 High Fidelity Audio Amplifier Board Module TDA7293
color:red,size:xxl
Subtotal: US$ 0
View My Cart

Copy and share this link on social network or send it to your friends

Copy
  • 100W Mono Digital Amplifier Board



    Product Information:



    The internal structure of TDA7293 is divided into three stages: the differential input stage is composed of bipolar transistors, and the drive stage and power output stage use FETs. This structure can integrate the advantages of bipolar transistors in low noise and power FETs in linearity, temperature coefficient and timbre. The voice is beautiful, taking into account the advantages of bipolar signal processing circuit and MOS power tube, and it has the advantages of low distortion, low noise, high withstand voltage, switch mute, overheat protection, short circuit protection, etc.



    Main Parameters:



    ● Product name: audio amplifier board

    ● Specification and model: XH-M170

    ● Channel type: mono

    ● Load type: 4~8 Ω speaker

    ● Power supply requirements: AC dual 12~32V

    ● Input cathode reactance: 100K Ω

    ● Output power: max. 100W

    ● Frequency response range: 20HZ~20KHZ

    ● Conversion rate: 15V/ μ s



    Product Features:



    1. This circuit is an official standard circuit, stable and reliable.

    2. The filter adopts large electrolysis with a withstand voltage of 50V and a capacity of 2200uf.

    3. Power supply voltage: double 12-36V ring, double 32V ring is recommended

    4. Output power: 85W * 1 undistorted rated power, peak power 100W

    5. Speakers above 100W can be easily pushed. Speaker impedance: 4-8 Ω

    6. PCB size: 60 * 36mm



    Notes For Use:



    Three wire transformers must be used. Double 12 to 32 transformers can be used. Heat sinks must be attached by yourself. Don't ask why. If it doesn't work, it doesn't work. Don't talk about theory. Neither DC nor batteries can work. If they are connected, they will explode. Neither DC nor batteries can work. If they are powered on, they will burn.
