PN5180 Module NFC Module Supports ISO15693 RFID High-frequency IC Card ICODE2 Read and Write ModuleItem NO.: PN5180

PN5180 Module NFC Module

Shipping list:

PN5180 card reader module, 1PCS

ICODE2/15693 card, 1 PCS

S50 keychain, 1PCS

2.54 row pin-13P, 1 PCS

Introduction to PN5180 module:

PN5180 can support more cards with different protocols (ISO/IEC 18092.14443 A/B, FeliCa, 15693),

Adding DPS function can increase the stability of reception (making it easier to pass through EMV and improving antenna feedback).

PN5180 supports card simulation and PEER TO peer mode, and is a new NFC chip.

The module adopts a widely used serial peripheral interface SPI

Overview:

PN5180 is an advanced multi-protocol NFC front-end with high output power, dynamic power control (DPC), adaptive waveform control (AWC), and adaptive receiver control (ARC), as well as multiple power saving functions. It can achieve efficient, stable, and reliable operation even under harsh conditions.

PN5180 is suitable for POS terminals and ensures interconnection with the new generation of NFC enabled mobile phones. The high-performance NFC front-end can meet the RF level EMV standard.

Characteristics:

Dynamic Power Control (DPC), which can optimize RF performance even in the event of antenna misalignment

Adaptive Waveform Control (AWC) automatically adjusts transmitter modulation to comply with RF standards

Adaptive Receiver Control (ARC) automatically adjusts receiver parameters to achieve reliable communication at all times

Automatic EMD processing without host interaction relaxes timing requirements on host controllers

Main advantages:

High RF output power

Fully compliant with all standards related to NFC, contactless operation, and EMVCo

Smaller antenna with active load demodulation supporting card simulation mode

Target application:

payment

Physical access control

E-government

industrial control
