1.54-Inch OLED Display LCD Module 4-Pin/7-Pin 128*64 SPI/IIC Interface SSD1309 Driver White/Blue/YellowItem NO.: OLED1.54
-
Customized Requirements
- Quantity
-
-
- Product Name: 1.54-Inch OLED Display LCD Module 4-Pin/7-Pin 128*64 SPI/IIC Interface SSD1309 Driver White/Blue/Yellow
- Item NO.: OLED1.54
- Weight: 0.1 kg = 0.2205 lb = 3.5274 oz
- Category: Electronic Modules > Display Module
- Tag: 4-Pin , OLED , Display , 7-Pin , SPI/IIC , 1.54-Inch , Display LCD Module , 128*64 , SSD1309
- Creation Time: 2024-03-27
1.54-Inch OLED Display LCD Module
Product Parameters:
● Driver chip: SSD1309
● Support interface: 7-pin SPI/4-pin IIC
● Resolution: 128 × sixty-four
● Display size: 1.54 inches
● Display color: white light/blue light/yellow light
● Module size: 42.4 × 38(mm)
● Display area: 35.052 × 17.516(mm)
● Pixel spacing: 0.274 × 0.274(mm)
● Pixel size: 0.254 × 0.254(mm)
● Number of pins: 7 pins/4 pins
● Perspective: Full perspective
● Operating temperature: -40 ℃~70 ℃
● Operating voltage: 3.3-5.5V
7-Pin Interface Definition:
● GND: Power ground
● VDD: Power supply positive (3.3-5V)
● SCL: SPI clock line
● SDA: SPI data cable
● RES: Reset pins
● DC: data/command selection pin
● CS: Chip selection signal: Low level effective (CS pins cannot be suspended. If chip selection is not needed, CS can be directly connected to the power supply ground, as suspension can cause unstable operation of OLED)
4-Pin Interface Definition:
● GND: Power ground
● VCC: Power supply positive (3.3-5V)
● SCL: SPI clock line
● SDA: SPI data cable
● RES: Reset pins
