- Product Name: GY-49 MAX44009 Digital Light Intensity Sensor Module I2c Interface High-Precision
- Item NO.: GY-49
- Weight: 0.1 kg = 0.2205 lb = 3.5274 oz
- Category: Electronic Modules > Sensor Module
- Tag: GY-49 , MAX44009 , Digital Light Intensity Sensor Module
- Creation Time: 2024-05-05
GY-49-MAX44009 Light Intensity Sensor Module
Product Information:
MAX44009 ambient light sensor provides 12C digital output, which can be used in portable products such as smart phones, laptops, industrial sensors, etc. MAX44009 has a 22-bit ultra-wide dynamic range (0.045 lumens to 188000 lumens).
Because it can detect extremely weak light, it can work ideally in dark glass environment. The spectral response of on-chip photodiodes is optimized for the response of human eyes to ambient light, and integrated with infrared and ultraviolet shielding. The adaptive gain circuit can automatically select the correct lumen range to optimize the test (count value/lumen).
Product Parameters:
● Working voltage: DC3-5 v
● Working current: 1uA
● Working temperature: - 40~85 ℃
● Module detection range: 0.045~188000 lux
● Communication mode: IIC
● Size: 10.5 * 13mm
