M18 Remote Diffuse Reflection E3F-DS300C1 Switch E3F-DS300C1 DC Three Wire NPN Normally OpenItem NO.: M18

M18 Remote Diffuse Reflection E3F-DS300C1 Switch

Product Information:

● Product name: Diffuse reflection photoelectric switch

● Product model: E3F1-DS300 series

● Working voltage: 6~36V DC/90~250V AC

● Working current: ≤ 300mA

● Output mode: inductive output

● Temperature resistance range: - 25~+75 ° C

● Operating frequency: 50Hz

● Sensing distance: 300cm

● Conductor length: 1.5mm

● Sensing object: non transparent object

● Product material: ABS

Application Scenario:

● Assembly line

● Chemical industry

● Automatic door

● CNC machine tool

● Robots

● Metallurgical industry

Model Analysis:

● Normally open: when there is no inductive object, the circuit is disconnected, and the inductive object circuit is closed

● Normally closed: the circuit is closed when there is no inductive object, and the inductive object circuit is disconnected

NPN: Take 24V voltage as an example: the output voltage is 0V when sensing objects, and 24V when not sensing

● PNP: Take 24V voltage as an example: the output voltage is 24V when sensing objects, and 0V when not sensing

Product Details:

● Probe: built-in intelligent sensor chip, transparent lens, ABS material

Shell: standard thread heat-resistant ABS, insulation and flame retardant, good stability

● Indicator light: LED indicator light is close to the left turning distance of the adjusting tail screw and far to the right turning distance

● Conductor: pure copper core, flame retardant sheath, good conductivity, strong aging resistance

Matters Needing Attention:

1. Do not use it outdoors or in rain

2. Do not pull the power cord of the switch forcibly

3. Do not strike the detection surface of the switch with a tough object

4. Do not use force to firm the switch during installation

5. It is strictly prohibited to use in strong corrosive environment

6. Do not run the wire in the same pipe as the power line or power line, but wire it separately
