Home>Electronic Modules>Audio Amplifier >MP3 Bluetooth Decoding Board Module DIY Car Speaker Amplifier Modification Bluetooth 4.1 Circuit Board Audio Receiver
MP3 Bluetooth Decoding Board Module DIY Car Speaker Amplifier Modification Bluetooth 4.1 Circuit Board Audio Receiver

MP3 Bluetooth Decoding Board Module DIY Car Speaker Amplifier Modification Bluetooth 4.1 Circuit Board Audio ReceiverItem NO.: XY-BT-L

US$ 4.60
Quantity
1Pcs
10Pcs
100Pcs
1000Pcs
5000Pcs
Customized Requirements
Quantity
Adding to cart succeed
MP3 Bluetooth Decoding Board Module DIY Car Speaker Amplifier Modification Bluetooth 4.1 Circuit Board Audio Receiver
color:red,size:xxl
Subtotal: US$ 0
View My Cart

Copy and share this link on social network or send it to your friends

Copy
  • Bluetooth Decoding Board 4.1



    Module Description:



    Bluetooth decoding board DIY, supporting Bluetooth 4.1, supporting automatic loopback function, supporting WAV+APE+FLAC+MP3 lossless decoding, stereo output, built-in TF card download, supporting U disk, TF card playback



    Parameter Properties:



    ●Power Supply:3.7-5V

    ●SNR:90dB

    ●THD+N:-70dB

    ●Crosstalk:-86dB

    ●DNR:91dB

    ●Support Profile:A2DP/AVCTP/AVDTP/AVRCP/HFP

    ●LOS:>15m



    Detailed Interface Description:



    ● Power interface: universal Micro USB 5V power supply

    ● 3.7-5V power supply pad: realize the modification of external 3.7-5V power supply

    ● U disk interface: supports playing MP3/WAV/APE/FLAC files in U disk and FAT16/32 file format

    ● TF card interface: supports playback of MP3/WAV/APE/FLAC files in TF card and FAT16/32 file format

    ● LED indication: the blue light of Bluetooth mode is always on, and the blue light of music mode is flashing

    ● 3.5mm stereo output: standard 3.5mm interface, output stereo sound source, can be inserted into earphones, and connected to power amplifiers and other devices



    Key Function:



    ● MODE: "Short press" to switch TF card, U disk and Bluetooth mode

    ● P/P: "Short press", play/pause

    ● NEXT/V+: "Short press" is the next song, and "Short press" is the volume increase

    ● PREV/V+: "Short press" is the last song, and "Long press" is the volume reduction

    ● RPT: "Short press" means single song/cycle switching
